80′ Articulating Boom Lift
Power Source
Power Source
| Auxiliary Power | 12 Volts DC |
| Capacity – Fuel Tank | 39 gal. / 147.63 L |
| Engine Type – Diesel | DEUTZ TD 2.9L Tier 4 Final 67 hp |
| Engine Type – Dual Fuel | Ford MSG425 84hp |
Performance
Performance
| Axle Oscillation | 0 in. / 0 m |
| Drive Speed – 2WD | 3 mph / 4.83 km/h |
| Drive Speed – 4WD | 3 mph / 4.83 km/h |
| Gradeability – 2WD | 30% |
| Gradeability – 4WD | 45% |
| Platform Capacity – Restricted | 1000 lb / 453.59 kg |
| Platform Capacity – Unrestricted | 500 lb / 226.80 kg |
| Swing | 360 Degrees |
| Swing Type | Continuous |
| Turning Radius – Outside (2WS) | 19 ft 8 in. / 5.99 m |
| Turning Radius – Outside (4WS) | 11 ft 7 in. / 3.53 m |
| Jib – Range of Articulation | 0 Degrees |
Dimensional Data
Dimensional Data
| Ground Clearance | 11 in. / 0.28 m |
| Machine Height | 9 ft 10 in. / 3 m |
| Machine Length | 36 ft 11 in. / 11.25 m |
| Machine Width | 8 ft 2 in. / 2.49 m |
| Platform Dimension A | 3 ft / 0.91 m |
| Platform Dimension B | 8 ft / 2.44 m |
| Tailswing | 2 ft 6 in. / 0.76 m |
| Tire Size | 15-625 Pneumatic |
Reach Specifications
Reach Specifications
| Horizontal Jib Rotation | 0 Degrees |
| Horizontal Outreach | 53 ft / 16.15 m |
| Platform Height | 80 ft / 24.38 m |
| Up and Over Height | 32 ft 1 in. / 9.78 m |
